USAGE:
Automatic flatbed die-cutting machine is a special equipment for creasing and die-cutting ordinary cartons, paper boxes, greeting cards, business cards, books, posters, etc. It is suitable for post-press processing and product packaging industries. The machine has the characteristics of compact structure, fine process, high pressure, high precision, convenient and reliable operation, etc.
MAIN SPECIFICATION:
| Model |
MS-1060B |
| Max Sheet Size |
1070x790mm |
| Min Sheet Size |
400x380mm |
| Max Cutting Size(Including waste edges) |
1060x760mm |
| Gripper Margin |
≥5mm |
| Cutting Rule Height |
23.8mm |
| Inner Chase Size |
1090x790mm |
| Stock Range |
80-1000gsm Cardboard ≤4mm Corrugated board |
| Max Cutting Pressure |
300T |
| Max Working Speed |
7500s/h |
| Max Feeding Pile Height |
1600mm(including wooden pallets) |
| Max Collecting Pile Height |
1400mm(including wooden pallets) |
| Dimension |
5600x4100x2300mm |
| Weight |
15000kgs |
| Main Motor Power |
11kw |
| Total Power Required |
17kw |
DETAILS:
FEEDING UNIT
1.Powerful paper suction feeder head, 4 suction and 5 delivery, the suction nozzle can adjust various paper suction angles according to the deformation of the paper, the air valve is treated with super-hard alloy, and 2000g cardboard and 4.5mm thick corrugated cardboard can also be easily fed
2.Fish scale paper feeder, maximum speed 125 sheets/min
3. Independent pre-stacking machine, the working paper pile can be maintained at any time during stacking
4. Adjustable side blowing device
5. Double circuit power-off protection feeder head anti-collision, stable and reliable
6. Push-pull dual-purpose side gauge
7. Electromechanical double sheet detection mechanism
FEEDING POSITIONING SECTION
1. Japan Nita paper feeding flat belt
2. PLC and electronic cam control the time of the whole machine
3. Side gauge and front gauge paper detection
4. In case of double sheet failure, the machine will be stopped after a delay, and the paper can be taken out smoothly from the paper feeding part
5. The program controls the start time of the air pump to ensure that each sheet of paper can accurately reach the front gauge position when the machine is enabled at any time, greatly shortening the adjustment time
6. The side gauge and front gauge are equipped with photoelectric detection switches
7. The main and auxiliary paper feeding tables can be alternated, and the feeder can operate without stopping
DIE CUTTING AND CREASING PART
1. Electric pressure regulating device
2. 40Cr crankshaft
3. Worm 40Cr hardened and ground
4. Photoelectric control frame in place detection, pneumatic locking
5. Right and left wall panels and upper and lower parts of QT450 resin sand process ductile iron
6. Die-cutting frame rotation device
7. Automatic cooling and lubrication system of lubricating oil in the main transmission box
8. Torque limit overload protection
9. 5 sets of anodized aluminum alloy tooth bars and precision positioning structures
10. Italian Yuyi pneumatic clutch brake device
11. German IWIS double pitch tooth bar chain
12. Taiwan precision intermittent divider
13. China Bedi Bedi synchronous belt
14. German Beck 80F composite air pump
15. Super hard steel plate 7mm piece
16. Adjustable movable frame combination set
17. Pneumatic locking device
18. Die-cutting plate center positioning mechanism
19. Hand wheel mechanism
20. Gear bar positioning fine adjustment mechanism
COLLECTING PART
1. Automatic auxiliary paper collection mechanism realizes main and auxiliary
2. Automatic paper collection conversion and automatic slapping (aligning) device, integrated brush, adjustable pressure
3. Anti-paper backflow photoelectric detection switch to prevent the paper collection table from being piled too high and paper on top
FAULT CONTROL AND SAFETY DETECTION
1. The whole machine has 31 safety detection points, all of which have passed PLC detection
2. Huichuan operation control + module
3. Kunlun Tongtai 15-inch human-machine main interface 7-inch secondary interface
4. Mager electronic rotary encoder and detection switch
5. Sine frequency converter
6. Detection points: main paper feeding upper limit, main paper feeding lower limit, auxiliary paper feeding upper limit, auxiliary paper feeding lower limit, paper feeding pile upper limit, paper feeding overheight, main paper collection upper limit; main paper collection bell warning; main paper collection lower limit; auxiliary paper collection enabled; auxiliary paper collection upper limit
Auxiliary paper collection lower limit: paper collection safety inspection, transmission surface operating surface front gauge electric eye, transmission surface front gauge electric eye, operating surface side gauge electric eye, side gauge electric eye, empty car electric eye, counting photoelectric switch; abnormal torque detection, anti-paper return control, plate national test steel plate extraction detection, collection strip detection, front and rear double length paper feeding angle detection, oil pressure protection switch, intermittent detection, air pressure protection switch
LUBRICATION SYSTEM
1. Automatic oil pump, forced lubrication system
2. High-performance oil temperature cooling condenser
3. Automatic intermittent lubrication system for transmission chain
4. Temperature control device for industrial heat exchanger in main electric control box
5. The gas system is mainly Japanese SMC, AirTAC
